Thomson Linear Ball Bushing Bearing SSU12OPN

SSU, Ball Bushing Bearing, 0.750, Open, Self-Aligning, Adjustable, Open Bearing, Not Corrosion Resistant, No Wipers. SSU12OPN universally self-aligning bearing offers twice the load capacity or eight times the travel life of our Super Ball Bushing bearing. A universal self-alignment feature optimizes load distribution between ball tracks and assures uniform ball loading over the entire length of the bearing plate. Its unique design with the steel band enables the bearing to preserve it’s ID fit-up and self-aligning capability over extended use. This patented product provides smooth, quiet, low drag linear movement at 6x the load capacity or 216 x the L10 travel life of a conventional steel linear ball bushing bearing. You can download the product's 3D Model step (stp) file below.

MPN: SSU12OPN

cad

Quantity

Request a quote

call_small Call: 1(866)577-4040

Specifications


type Bushing Only Open
outer diameter 31.750 mm / 1.25 in
nominal diameter 19.050 mm / 0.75 in
use with shafting class L
temperature max 85 °C / 185 °F
single twin Single
self alignment Self-aligning
food grade rated Not Food Grade
roll pack No Roll Pack
closed open Open
adjustable not adjustable Adjustable
