Please Note: Photo may not represent actual item, please refer to title and product specifications for all details.
Rosta Tensioner Devices SE-G
SE-G type of Tensioning elements marked with yellow dot are particularly designed for ''outdoor'' applications such as building machines. The tenshioner devices are made of zinc-plated steel.
SE-G types are equipped with oil resistant synthetic inserts for the applications in oily areas, like in gearboxes and crank-cases.
MPN: 06 013 201
Specifications
| P | 8 |
| O | 6 |
| Type | SE 11-G |
| F max. with J1 [N] | 96 |
| F max. with J1 [N] | 96 |
| s max with J1 [N] | 40 |
| øD | 35 |
| E | 51 |
| G | 5 |
| H | M6 |
| J1 | 80 |
| J2 | 60 |
| K | 20 |
| L | 90 |
| M ca. | 20 |
| N | 22 |
| øT | 8.5 |
| U | 16.5 |
| Weight [kg] | 0.2 |
