Thomson

PC25LX004B10-0050XM1 - Precision Linear Actuator

PC25LX004B10-0050XM1 precision linear actuator is designed to deliver high performance in applications requiring continuous duty operation. It provides the highest thrust and speed of any electric actuator and allows you to design more compact machinery with maximum throughput. Often chosen as a clean and efficient alternative to fluid power solutions, precision linear actuators draw energy only on demand and operate more quietly than pneumatics. It also has mounting accessories according to pneumatic ISO standard.

MPN: PC25LX004B10-0050XM1

Quantity

Request a quote

call_small Call: 1(866)577-4040

Specifications


adapter options rod end Male thread, M10x1.25
brake No Brake
cylinder mounting options No Mounting option included
ip rating IP65
motor type Motor not included
profile size 34 x 34 mm
screw type Ball
temperature max 70 °C
temperature min -20 °C

Related Literature & Videos


precision_linear_actuators_cten.pdf
