Thomson

MF07B130 A00R135 Linear Motion System

MF07B130-A00R135 can be configured to work in harsh environments, at high speeds and in high-precision applications — all while striking a balance of performance, life and cost. RediMount motor mounting adapter kits are now available as standard on all systems, making the process of choosing and mounting a motor much faster and easier. Wash down protected versions are also available.

MPN: MF07B130-A00R135

Quantity

Request a quote

call_small Call: 1(866)577-4040

Specifications


shaft quantity Single Shaft
shaft orientation Right Angle
shaft configuration Shaft On Left Side
protection option Standard Protection
profile size width x height 86 x 75 mm
guide Ball
active 1
drive Belt
belt type STD5-40

Related Literature & Videos


linear_motion_systems_cten.pdf
