Thomson

Thomson SSU12 CR Linear Ball Bushing Closed Bearing

SSU, Ball Bushing Bearing, 0.750, Self-Aligning, Closed, Corrosion Resistant, No Wipers. SSU12-CR universally self-aligning bearings offer twice the load capacity or eight times the travel life of our Super Ball Bushing bearing. A universal self-alignment feature optimizes load distribution between ball tracks and assures uniform ball loading over the entire length of the bearing plate. Its unique design with the steel band enables the bearing to preserve it’s ID fit-up and self-aligning capability over extended use. This patented product provides smooth, quiet, low drag linear movement at 6x the load capacity or 216 x the L10 travel life of a conventional steel linear ball bushing bearing. You can download the 3D model below.

MPN: SSU12-CR

cad

Quantity

Request a quote

call_small Call: 1(866)577-4040

Specifications


corrosion resistant option LBBB Ball Corrosion Resistant
roll pack No Roll Pack
self alignment Self-aligning
temperature max 85 °C / 185 °F
use with shafting class L
nominal diameter 19.050 mm / 0.75 in
outer diameter 31.750 mm / 1.25 in
type Bushing Only Closed
adjustable not adjustable Not Adjustable
closed open Closed
food grade rated Not Food Grade
single twin Single
