Thomson End Supported Roundrail Linear Guide System 1BA06AH0L72.000

Linear Guide, Single Shaft, 1BA, Industry Standard Round Shafts, ASB Support, 2 Pillow Blocks, 0.38 in, 160 lbf Dynamic Load Capacity. RoundRail linear guides feature Thomson’s patented self-aligning Super Ball Bushing Bearings with up to 27X the life or 3X the load capacity of conventional bearings. It is end supported for gantry style or ‘bridge’ applications and it's used to provide increased stability or torque resistance in linear system applications. You can download the product's 3D model below.

MPN: 1BA06AH0L72.000

cad

Quantity

Request a quote

call_small Call: 1(866)577-4040

Specifications


diameter 10 mm (0.380 in)
shaft material Steel
support material Aluminum
block material Aluminum 6061, Delrin, Nitrile
max temperature 85 °C (185 °F)
type End Supported, Two Pillow Blocks
