Please Note: Photo may not represent actual item, please refer to title and product specifications for all details.
Thomson Continuous Supported Roundrail Linear Guide System 1DA08J00L72.000
Linear Guide, Single Shaft, 1DA, Low Profile, SSRA Side-Mounted Shaft Support Rail, Continuous Support, 2 Pillow Blocks, 0.5 in, 240 N Dynamic Load Capacity. RoundRail linear guides feature the new patented Super Smart Ball Bushing Bearings for up to 27X the life or 3X the load capacity of conventional bearings. It's used to provide increased stability or torque resistance in linear system applications. Continuously supported for maximum (down- and side-) load applications without concerns for shaft deflection and it's side-mounted geometry for increased mounting flexibility. You can download the product's 3D model below.
MPN: 1DA08J00L72.000
Specifications
| type | Continuous Support, Side Mounted - Two Pillow Blocks |
| max temperature | 85 °C (185 °F) |
| block material | Aluminum 6061, Delrin, Nitrile |
| environment | Standard |
| shaft material | Carbon Steel (AISI 1566), Aluminum 6074 |
| diameter | 13 mm (0.500 in) |
