Please Note: Photo may not represent actual item, please refer to title and product specifications for all details.

Thomson Continuous Supported Roundrail Linear Guide System 1DA08K00L72.000

Linear Guide, Single Shaft, 1DA, Low Profile, SSRA Side-Mounted Shaft Support Rail, Continuous Support, 1 Twin Pillow Block, 0.5 in, 240 N Dynamic Load Capacity. RoundRail linear guides feature the new patented Super Smart Ball Bushing Bearings for up to 27X the life or 3X the load capacity of conventional bearings. It's used to provide increased stability or torque resistance in linear system applications. Continuously supported for maximum (down- and side-) load applications without concerns for shaft deflection and it's side-mounted geometry for increased mounting flexibility. You can download the product's 3D model below.

MPN: 1DA08K00L72.000

0 Reviews - Be the first to review this item.

Quantity

Request a quote

Call: 1(866)577-4040

Specifications

type	Continuous Support, Side Mounted - One Twin Pillow Block
max temperature	85 °C (185 °F)
block material	Aluminum 6061, Delrin, Nitrile

environment	Standard
shaft material	Carbon Steel (AISI 1566), Aluminum 6071
diameter	13 mm (0.500 in)
